CAR NUMBER: FS AUSTRIA 96
                                FORMULA BHARAT 68


ENGINE

  • HONDA CBR600 RR PC37

  • Fuel Type – 98 RON Gasoline

  • Power – 79BHP at 11000 RPM

  • Torque – 57 Nm  at 8000RPM

ELECTRONICS

  • MoTeC M400 ECU

  • AiM EVO4 data logger in conjunction with myRIO

SUSPENSION & STEERING

  • Independent double-wishbone pullrod front and pushrod rear suspension

  • Öhlins dampers

  • Adjustable ackerman

CHASSIS

  • Front and rear single piece tubular space frame

  • Fusion welding ER70-S6filler

  • Material – Chromoly 4130 steel

  • Body – Carbon fibre bodywork

  • In – house vacuum bagged

TIRES & WHEELS

  • Hoosier 18 x 7.5 x 10 Racing Slicks

  • 10 inch Keizer rims – Aluminium wheel centers

BRAKES

  • Floating rotor braking system

  • Front Calipers: ISR CP 22-048 OC

  • Rear Calipers: PS1 Wilwood

ERGONOMICS

  • Driver Size Adjustments:

                         Fixed seat and steering wheel.

                         Pedal adjusts fore and aft 25mm from the center position

  • Seat: Wet lay-up carbon, Padded lumbar and knee protection, 60mm Ethafoam head support

  • Driver Visibility: 210 degrees Side Visibility

TRANSMISSION

  • 6-speed sequential gearbox

  • Drexler limited slip clutch pack type differential with six torque biasing ratio

  • Electropneumatic clutching, shifting with titanium driveshafts





FMX8
